6RJ Series High Speed Tripping Relays

6RJ24 High Burden Electrical Reset Trip & Lockout Relay

Summary

Features

  • High speed operation
  • High burden
  • Electrical reset contacts
  • Independent hand reset flag
  • 5 or 10 contacts
  • Equivalent function to MVAJ24
  • 2HSM516 specification

Application

The effect of a fault on a power system is dependent on the speed with which the fault can be detected & isolated. The 6RJ Series multi-contact high-speed trip relays are used for this isolating function roviding simultaneous tripping outputs.

A high speed coil provides fast operation (less than 10ms at nominal voltage including bounce), with specially constructed anti bounce buffers ensuring effective damping of the contacts to avoid excessive bounce.
